| Operating Frequency | X-band |
|---|
| Scan Type | 2D phased array |
|---|
| Range | 15 km |
|---|
| Detection Distance | ≥ 8 km — small rotary-wing UAV (RCS 0.01 m²)
≥ 15 km — medium fixed-wing UAV (RCS 1 m²)
≥ 15 km — personnel
≥ 15 km — helicopter, vehicle |
|---|
| Horizontal Field of View | 90° / 360° |
|---|
| Elevation Field of View | -2° to +45° |
|---|
| Detection Height | 2000 m |
|---|
| Angle Accuracy | Azimuth ≤ 0.4° (RMS), elevation ≤ 0.4° (RMS) |
|---|
| Data Rate | 0.5 Hz (TWS) / 4 Hz (TAS) |
|---|
| Simultaneous Tracking | TWS ≥ 500, TAS 2 per face |
|---|
| Radial Velocity Range | 1-150 m/s |
|---|
| Power Supply | DC 36-52 V (with AC 220 V → DC 48 V adapter) |
|---|
