Technical Specifications
| Operating Frequencies (MHz) | GPS L1 C/A — 1575.42BDS B1 — 1561.098GLONASS L1 — 1602GPS L2 C/A — 1227.6GPS L5 — 1176.45BDS B1C — 1575.42BDS B2I — 1207.14BDS B2A — 1176.45BDS B3I — 1268.52GLONASS L2 — 1246Galileo E1 — 1575.42Galileo E5A — 1176.45Galileo E5B — 1207.14 |
|---|---|
| Control Mode | Directional drone deterrence, output power -70 dBm to +20 dBm |
| Power Adjustment | 1 dB steps |
| Startup Time | < 60 s (RMS) |
| Intrusion Time | < 10 s |
| Communication Protocol | UDP |
| Effective Range | < 20 km |
